Model Code
C17105U
FRAMESET
Frame - SuperX Carbon
Proportional Responseconstruction
internal cable routing
12x142mm thru-axle
UDH BSA68mm threaded BB
flat mountdisc
integrated seatpost binder
Fork - SuperX Carbon
integrated crownrace
12x100mm thru-axle
flat mountdisc
internal routing
1-1/8" to 1-1/2"Delta steerer
55mm offset
Headset - Integrated 1-1/8" - 1.5"
DRIVETRAIN
Front Derailleur - Shimano GRX 820
braze-on
Rear Derailleur - Shimano GRX 820
Shadow RD+ShiftersShimano GRX 820
12-speedChainShimano M8100
12-speedCrankShimano RX 820
48/32Rear CogsShimano 105 7100
11-36 12-speed
Bottom Bracket - Shimano BSA 68
BRAKES
Brakes - Shimano GRX 820
160/160mmCL800 rotors
Brake Levers - Shimano GRX RX820 hydraulic disc
WHEELS
Hubs(F) DT Swiss 370
12x100mm centerlock /(R) DT Swiss 370
12x142mm centerlock
Rims - DT Swiss G1800 24h
tubeless ready
Spokes - DT Swiss Aero Comp
Tyres - Vittoria Terreno T50
700x40c tubeless ready
COMPONENTS
Handlebar - Cannondale C2, 7050 Alloy Compact
Grips - Cannondale Bar Tape 3.5mm
Stem - Cannondale C1 Conceal
Alloy, 31.8, -6°SaddlePrologo Dimension AGX STN
Seatpost - Cannondale C1 Aero 27 Carbon
SmartSense compatible, 0mm offset(46cm)
20mm offset (51-61cm)
Connectivity - Cannondale Wheel Sensor
SIZES
46, 51, 54, 56, 58, 61
