Frameset
| Frame | Double Butted Alloy E-Bike Frame, Internal Cables |
| Fork | Aluminum w/ Light Mount, 12x100 TA, PS |
Drivetrain
| Rear Shifter | Shimano CUES SL-U4000-9R, 9sp |
| Rear Derailleur | Shimano CUES RD-U4020, 9sp, SGS |
| Crankset | Shimano FC-EM600, 38T, 165mm |
| Cassette | Shimano CUES CS-LG300-9, 11-36T, 9sp |
| Chain | KMC eGlide, 9sp |
Brakes
| Front Brake | Tektro HD-M280 Auriga, 2-P, Resin Pads, Anti-Vibration |
| Front Brake Rotor | Tektro TR160-52, 160mm, 1.8mm Thickness , 6-bolt |
| Rear Brake | Tektro HD-M280 Auriga, 2-P, Resin Pads, Anti-Vibration |
| Rear Brake Rotor | Tektro TR160-52, 160mm, 1.8mm Thickness , 6-bolt |
| Brake Levers | Tektro HD-M280 Auriga |
Components
| Handlebar | Norco Scene Aluminum, 660mm, 60mm Rise, 30Deg Backsweep |
| Stem | Norco Aluminum, 70mm (S/M) -80mm (M/L), 17deg Riser, 31.8 clamp |
| Seatpost | TranzX YSP18PLQ, 31.6mm, 100mm |
| Headset | Tapered 1-1/8"- 1.5",(ZS44/28.6 | ZS56/40) |
| Saddle | Scene Comfort Saddle w/Elastomer Suspension, 225mm W x 269mm L |
| Grips | Dual Density Ergonomic Single Lock, 133mm Length |
| Seatpost Clamp | Norco Alloy QR, 31.8mm ID |
Wheels
| Front Hub | Formula DC-221T, 15x100mm TA, 32h, 6-bolt |
| Rear Hub | Formula DC-142,12x142mm Boost, HG, 32h, 6-bolt |
| Rims | Alloy DW Disc w/27mm ID, 32h |
| Front Tire | Kenda Kwick Seven5, 27.5 x 2.2", 30 TPI, Wire |
| Rear Tire | Kenda Kwick Seven5, 27.5 x 2.2", 30 TPI, Wire |
| Spokes/Nipples | 13G Stainless Steel w/Brass Nipples 2.0MMX16MM - Black |
Electric Components
| Drive Unit | Shimano DU-EP600, 85 N.m |
| Battery | Shimano BT-EN605, 504 Wh |
| External Charging Adaptor | Shimano EC-E6002, 1.8A |
| Display | Shimano SC-EN500, 22.2mm Clamp Band |
Additional Info
| Sensor | Shimano EW-SS300 Sensor |
