Driven by the high-performance Bosch Performance Line CX Smart System (100 Nm) and a massive, integrated 800 Wh Bosch PowerTube battery, it delivers exceptional power and an extended range of up to 160 km for long-distance adventures.
Designed as a rugged "Plus+" utility all-rounder, it supports a heavy-duty 170 kg total system weight capacity. Comfort and control are prioritized via an active riding posture, a plush SR Suntour Mobie34 suspension fork with 120 mm of travel, an aluminum suspension seatpost, and grippy Schwalbe Smart Sam all-road tires. Fully outfitted for daily use and expeditions out of the box, it includes high-output LED lighting (featuring a rear brake light), extra-long aluminum mudguards, a sturdy kickstand, an MIK HD rear carrier, and dependable Shimano hydraulic disc brakes with oversized rotors.
Detailed Specifications
E-System & Electronics
| Feature |
Specification |
| Motor |
Bosch Performance Line CX Smart System (36 V / 250 W / 100 Nm torque) |
| Battery |
Bosch PowerTube Li-Ion (800 Wh / 22.2 Ah) |
| Display |
Bosch Purion 200 color display with walk assist |
| Range |
Up to 160 km |
| Max Speed |
25 km/h |
Frame & Suspension
| Feature |
Specification |
| Frame Options |
Diamond, Trapez, Wave (Step-Through) |
| Fork |
SR Suntour Mobie34, 110x15 mm thru-axle, 120 mm travel |
| Max System Weight |
170 kg (Rider + Bike + Luggage) |
| Total Bike Weight |
Approx. 29–33 kg depending on frame style (incl. battery) |
Drivetrain & Brakes
| Feature |
Specification |
| Rear Derailleur |
Shimano Cues, 9-speed |
| Cassette |
Shimano Cues Linkglide |
| Chain |
Shimano CN-LG500 |
| Brakes |
Hydraulic Disc Brakes (Front: 203 mm / Rear: 180 mm) |
| Gear Ratio |
Front: 42T, Rear: 11–46T |
Wheels & Cockpit
| Feature |
Specification |
| Tires |
Schwalbe Smart Sam Black Reflex, 57-622 (29") |
| Wheel Size |
29" |
| Handlebars |
Allroad Riser |
| Grips |
Ergon GS10 Evo |
| Stem |
Cockpit 2.0, adjustable, 65 mm |
| Saddle |
Selle Royal Vivo |
| Seatpost |
Aluminium, suspension |
Accessories & Hardware
| Feature |
Specification |
| Headlight |
Herrmans MR9, LED |
| Tail Light |
Trelock COB Line with brake light, LED |
| Pannier Rack |
MIK HD Rear Carrier (max. load 27 kg) |
| Mudguards |
Aluminium, extra long with splash guard |
| Kickstand |
Rear stand, adjustable |
| Pedals |
MTB Flat, aluminium with reflector |
