TECHNICAL INFORMATION
Mount: Center Lock
Diameter: 140 mm, 160 mm
Design: 2-piece
Rotor Material: Stainless steel outer and aluminium core sandwich construction
Spider Material: Aluminium
APPROVED FOR
Brake Compatibility: BR-M9100, BR-M9120, BR-M9110-R, BR-M9000, BR-M9020, BR-M8100, BR-M8120, BR-M8110-R, BR-M8000, BR-M8020, BR-M7100, BR-M7120, BR-M7110-R, BR-M7000, BR-M6100, BR-M6120, BR-M6000, BR-MT520, BR-MT420, BR-M820, BR-M640, BR-U8000, BR-U8020, BR-S7000, BR-S700, BR-R9270, BR-R9170, BR-R8170, BR-R8070, BR-R7170, BR-R7070, BR-4770, BR-RS805, BR-R785, BR-RS785, BR-RS505, BR-RS405, BR-RX820, BR-RX820-LE, BR-RX810, BR-RX400
Brake Pad Compatibility: sintered*, organic
* with BR-S700 and BR-S7000 only organic
COMPATIBILITY
- For brake pads with narrow pad shape
- Lockring with internal teeth: compatible with 9/10 mm quick release and 12 mm thru-axle
- For 15 mm and 20 mm thru-axles, use the SM-HB20 lockring instead
FEATURES
- FREEZA Ice Technology and sandwich construction for even faster heat dissipation
- First-class reliable braking performance on long, steep descents
- Specially designed for low noise and low weight
- Lockring made of anodised aluminium (internal toothing)
- Painted spider, polished rotor
Weight:
- 140 mm: 96 g
