Frameset
Frame:
Kaius 01 Gen 2 | 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Full Mount - UDH | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Kaius 01 Gen 2 | 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Stem:
BMC RSM 01 | Integrated Cockpit System Technology
Handlebar:
BMC HB D4 03, 0, 12 | Alloy 6061 | Endurance Geometry | 125mm drop, 70mm reach, 12° flare
Grips:
BMC Tacky 3mm
Seat
Seatpost:
Teammachine SLR 01 Gen 5 | 01 Premium Carbon Aero Shaped Seatpost | 0mm Offset Size 47-51 and 10mm Offset Size 54-61
Saddle:
Fizik Vento Argo X5 | 140mm
Drivetrain
Crankset:
SRAM Rival XPLR AXS Wide (FC-RIV-1W-E1)
Chainrings:
42T
Cassette:
SRAM Rival XPLR (CS-XG-1351-E1)
Cassette Size:
10-46T
Chain:
SRAM Rival (CN-RIV-E1)
Rear Derailleur:
SRAM Rival XPLR AXS (RD-RIV-1E-E1)
Shifters:
SRAM Rival AXS (ED-RIV-E1)
Gears:
1 x 13
Bottom Bracket:
SRAM DUB T47 85.5 Road Wide Bottom Bracket (BB-DUB-T47-A1)
Brakes
Brake Levers / Calipers:
SRAM Rival AXS (ED-RIV-E1)
Rotors:
SRAM Paceline Rotor (RT-PLN-A2)
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
CG 40 Carbon | Tubeless Ready | 40mm
Hubs (F/R):
TXC-812 & TXC-2406 Center Lock
Tires:
Continental Terra Competition Race Rapid | Tubeless | 45mm
Tubeless Information:
Tubeless Rim | Tubeless Tires
Accessories
In the Box:
Aerocore Bottle Cages
Additional Information
Tire Clearance:
52mm measured tire
Weight without Pedals:
8.3kg | Size 54 as pictured with all accessories
ASTM Classification:
Level 2
System Weight Limit:
120kg
