Frameset
Frame:
Kaius 01 Gen 2 | 01 Premium Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Full Mount - UDH | TCC Race Compliance Level | Flat Mount Disc | 12 x 142mm Thru-Axle
Fork:
Kaius 01 Gen 2 | 01 Premium Carbon | ICS Technology, Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Handlebar:
ICS Carbon Aero Gen 2 | One-Piece Full Carbon Cockpit | 135mm drop, 81mm reach, 12° flare
Grips:
BMC Tacky 3mm
Seat
Seatpost:
Teammachine SLR 01 Gen 5 | 01 Premium Carbon Aero Shaped Seatpost | 0mm Offset Size 47-51 and 10mm Offset Size 54-61
Saddle:
Fizik Vento Argo X3 | Kium rails | 140mm
Drivetrain
Crankset:
SRAM Force AXS Wide (FC-FRC-1WP-E1)
Chainrings:
42T
Power Meter:
SRAM Force XPLR AXS Power Meter | Single Side (FC-FRC-1WP-E1)
Cassette:
SRAM Force XPLR (CS-XG-1371-E1)
Cassette Size:
10-46T
Chain:
SRAM Force (CN-FRC-E1)
Rear Derailleur:
SRAM Force XPLR AXS (RD-FRC-1E-E1)
Shifters:
SRAM Force AXS (ED-FRC-E1)
Gears:
1 x 13
Bottom Bracket:
SRAM DUB T47 85.5 Road Wide Bottom Bracket (BB-DUB-T47-A1)
Brakes
Brake Levers / Calipers:
SRAM Force AXS (ED-FRC-E1)
Rotors:
SRAM CenterLine X Rotor (RT-CLN-X-A2)
Rotor Size (F/R):
160 / 160mm
Wheels
Rims:
CG 39 Carbon | Tubeless Ready | 39mm
Hubs (F/R):
CG 39 | Star Ratchet System | Straightpull Design | Center Lock
Tires:
Continental Terra Competition Race Rapid | Tubeless | 45mm
Tubeless Information:
Tubeless Rim | Tubeless Tires
Accessories
In the Box:
Aerocore Bottle Cages | Computer mount for Garmin, Wahoo and GoPro mount
Additional Information
Tire Clearance:
52mm measured tire
Weight without Pedals:
7.8kg | Size 54 as pictured with all accessories
ASTM Classification:
Level 2
System Weight Limit:
120kg
